2SD/2.5SD
SD Series (with plastic impeller)MOTOR AND PUMP
Rewindable motor
Single-phase:220-240V/50Hz
Equip with start control box
Pumps are designed by casing stressed
NEMA dimension standards curve to lerance
according to lSO 9001
OPERATING CONDITIONS
Maximum fluid temperature up to +35℃
Maximum sand content:0.25%
Minimum well diameter:2”
APPLICATIONS
For water supply from wells or reservoirs
For domestic use,for civil and industrial applications
For garden use and irrigation
OPTIONS ON REQUEST
Special mechanical seal
Single phase motor
